Nanofiltration Membrane
The nanofiltration membrane can reject both monovalent and divalent ions differently. This feature enables selective permeation. This process has various applications, such as PR solutions, dyes, special chemicals, expensive raw material recovery, and pretreatment. The pretreatment removes some monovalent ions and rejects divalent ions in seawater processes.
Nanofiltration Membrane Specification
| Model | Flow Rate | Naco | MgS04 | Diameter/ |
|---|---|---|---|---|
| (GPD,m3/d) | Rejection(%) | Rejection (%) | Length (inch) | |
| NE8040-40* | 10,000 (37.9) | 20-40 | 8.0 / 40 | |
| NE8040-70* | 7,000 (26.5) | 40-70 | 97 | 8.0 / 40 |
| NE8040-90* | 8,000 (30.3) | 85-95 | 97 | 8.0 / 40 |
| NE4040-40* | 2,100 (9.45) | 20-40 | 4.0 / 40 | |
| NE4040-70* | 1,500 (5.7) | 40-70 | 97 | 4.0 / 40 |
| NE4040-90* | 1,700 (6.0) | 85-95 | 97 | 4.0 / 40 |
| NE Standard test conditions: NaCl 2,000 mg/L, Pressure 75 psig, Temperature 25°C, pH 6.5-7.0 Recovery 15% |
| MgSO4 rejection test conditions: MgSO4 2,000 mg/L, Pressure 75 psig, Temperature 25°C, pH 6.5-7.0 Recovery 15% |
| The stated data were obtained after 30 minutes of operation |
Get Nanofiltration Membrane From PT GLS
PT Gapura Liqua Solutions reflect our commitment to control the product quality by working closely with our strategic business partners, mostly leading components manufacturing firms in the field of water treatment, waste water treatment, desalination, and resources recovery.
You will guarantee product originality, advisory for your water system, and taking care by our skilled engineer to meet your business goals. Contact us now!
